Function library
AIF1In
l
249
EDBCSXS064 EN 4.0
Codes
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0136
Control words
Hexadecimal value is bit−coded.
Read only
1 CTRLWORD
0
{hex}
FFFF Control word C0135
2 CTRLWORD
CAN control word
3 CTRLWORD
AIF control word
C0855
Digital process data input words
are indicated on the AIF interface
(AIF1_IN)
Hexadecimal value is bit−coded.
Read only
^ 248
1 AIF1 IN bits
0000
{hex}
FFFF Input word 2 (bit 0 ... 15)
2 AIF1 IN bits
Input word 3 (bit 0 ... 15)
C0856
Analog process data input words
are indicated decimally on the
AIF interface (AIF1_IN)
100.00% = 16384
Read only
^ 248
1 AIF1 IN words
−199.99
{0.01 %}
199.99 Input word 1
2 AIF1 IN words
Input word 2
3 AIF1 IN words
Input word 3
C0857 AIF1 IN phi
32 bits of phase information on
the AIF interface (AIF1_IN)
Read only
^ 248
−2147483648
{1}
2147483647
