Function library
Speed (speed control)
Changing the direction of rotation
l
325
EDBCSXS064 EN 4.0
12.27.1
Changing the direction of rotation
By means of the inputs SPEED−RLQ.Cw (C7411/1) and SPEED−RLQ.CCw (C7411/2) of the
function block "Speed", two functions are carried out:
ƒ
Changing the direction of rotation
ƒ
Set quick stop (QSP)
)
Note!
Both inputs only have an effect on the speed setpoint.
(
Stop!
The speed and direction of torque have to be selected according to the
application.
Signal name
Response
SPEED−RLQ.CW
SPEED−RLQ.CCW
Rotation
Quick stop (QSP)
0
0
None
Yes
1
0
To the right
No
0
1
To the left
No
1
1
No change
No
