Function library
FCODE (free codes)
l
311
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0471 FCODE 32bit
0
Hexadecimal 32−bit
interpretation of C0470
^ 309
0
{1}
4294967295
C0472 FCODE analog
Freely configurable code for
relative analog signals
^ 309
1
0.0
−199.99
{0.01 %}
199.99 FCODE_bC472_1_a
2
0.0
FCODE_bC472_2_a
3
100.0
FCODE_bC472_3_a
4
0.0
FCODE_bC472_4_a
...
...
...
20
0.0
FCODE_bC472_20_a
C0473
Freely configurable code for
absolute analog signals
^ 309
1 FCODE abs
1
−32767
{1}
32767
2 FCODE abs
1
3 FCODE abs
0
... ...
...
10 FCODE abs
0
C0474
Freely configurable code for
phase signals
^ 309
1 FCODE PH
0
−2147483647
{1}
2147483647
... ...
...
5 FCODE PH
0
C0475
Freely configurable code for
phase difference signals
^ 309
1 FCODE DF
0
−16000
{1 rpm}
16000
2 FCODE DF
0
