Appendix
Code table
l
390
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
10 User menu
0.00
Not assigned
11 User menu
11.00
C0011
Nmax
Input of the maximum speed
12 User menu
0.00
Not assigned
13 User menu
0.00
Not assigned
14 User menu
105.00
C0105
QSP Tif
Input of quick stop deceleration
time
15 User menu
0.00
Not assigned
16 User menu
70.00
C0070
Vp speed CTRL
Input of speed controller gain
(Vp)
17 User menu
71.00
C0071
Tn speed CTRL
Input of speed controller reset
time (Tn)
18 User menu
0.00
Not assigned
19 User menu
2100.00
C2100
Time slice
Input of time dial for cycl. task
20 User menu
2102.00
C2102
Task switch
Selection of the switching
function for cycl. task
21 User menu
2104.00
C2104
PLC autorun
Autom. start of the PLC program
after mains power−up
22 User menu
2106.00
C2106
Download protect
Write protection of the PLC
program
23 User menu
2108.00
C2108
PLC run/stop
Control of the PLC program
24 User menu
2111.00
C2111
GDC ID
Creation date of the PLC program
25 User menu
2113.00
C2113
PLC prog name
Name of the PLC program
26 User menu
2115.00
C2115
T−fct Credit
Number of technology units
27 User menu
0.00
Not assigned
28 User menu
0.00
Not assigned
29 User menu
0.00
Not assigned
30 User menu
0.00
Not assigned
31 User menu
94.00
C0094
Password
Parameter access protection for
the keypad
32 User menu
3.00
C0003
Par save
Save parameter set
[C0540] X8 Signal out
2
Function of the digital frequency
output signals on X8 (DFOUT)
^ 304
^ 103
0
DFOUT in [%]
1
DFOUT in [rpm]
2
Encoder simulation + zero pulse
®
DFOUT
C0545 PH offset
0
Phase offset
^ 304
0
{1 inc}
65535 1 revolution = 65535 increments
C0547 DIS: AN−IN
Analog signal on the input of the
DFOUT block
Read only
^ 304
−199.99
{0.00 %}
199.99
C0549 DIS: DF−IN
Speed on the input of the DFOUT
block
Only display
^ 304
−32767
{1 rpm}
32767
C0559 SD8 filter t
1
Filter time constant (SD8)
1
{1 ms}
200 Example:
If the setting is "10 ms", a
SD8−TRIP is actuated after 10 ms.
