Function library
Torque (torque control)
Setting of motor control
l
354
EDBCSXS064 EN 4.0
12.28.4
Setting of motor control
12.28.4.1
Torque setpoint
ƒ
The maximum possible torque is calculated from the motor parameters by the
controller. It can be read in C0057.
ƒ
Torque setpoint "torque setpoint"#
– TORQUE−MCTRL.MAdd (C7531/1) acts as a torque setpoint.
– The speed controllers carry out a monitoring function.
– The torque setpoint is defined in [%] of the maximum possible torque.
– Negative values cause a torque in CCW rotation of the motor.
– Positive values cause a torque in CW rotation of the motor.
12.28.4.2
Torque limitation
An external torque limitation can be set via TORQUE−MCTRL.NegLoMLim (C7531/3) and
TORQUE−MCTRL.HiMLim (C7531/4). This enables you to select different torques for the
quadrants "driving" and "braking".
ƒ
TORQUE−MCTRL.HiMLim is the limit in the positive direction in [%] of the maximum
possible torque.
ƒ
TORQUE−MCTRL.HoMLim is the limit in the negative direction in [%] of the
maximum possible torque.
The maximum possible torque (C0057) depends on the motor parameters (C0022, C0081,
C0087, C0088).
)
Note!
In case of quick stop (QSP), the torque limitation is switched to an inactive
state, i. e. the operation runs with ±100 %.
