Function library
Speed (speed control)
Holding brake control
l
340
EDBCSXS064 EN 4.0
12.27.4
Holding brake control
By means of this function, you can control a motor holding brake. Possible applications are:
ƒ
Hoists
ƒ
Traverse drives
ƒ
Drives with active loads
Codes
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0195 BRK T act
99.9
Closing time of the motor
holding brake
^ 340
^ 360
^ 102
0.0
{0.1 sec}
99.9 During the time set the drive
continues to generate a torque.
After the set time is expired, the
status "mechanical brake closed"
is reached.
C0196 BRK T rel
0.0
Opening time of the motor
holding brake
^ 340
^ 360
^ 102
0.0
{0.1 sec}
60.0 During the time set the drive can
generate the torque set under
C0244 against the holding brake.
After the set time is expired, the
status "mechanical brake
opened" is reached.
C0244 BRK M set
0.00
Holding torque of the drive
against the motor holding brake
^ 340
^ 360
^ 102
−199.99
{0.01 %}
199.99 Referring to M
max
(C0057).
During the time set in C0196 the
drive generates the set torque
against the holding brake.
