Function library
InNeg
l
314
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C7130
Display of the analog input
signals in the InNeg function
block (signal inversion)
^ 313
−32768
(= −199.9 %)
{1}
32767
(= 199.9 %)
1 InNeg−AnV
InNeg−AnIn1
2 InNeg−AnV
InNeg−AnIn2
C7131
Selection of the analog input
signals for the InNeg function
block (signal inversion)
^ 313
1 InNeg−An
1000
FIXED 0 % (not assigned)
Source for InNeg−AnIn1
2 InNeg−An
1000
FIXED 0 % (not assigned)
Source for InNeg−AnIn2
For possible signals see "selection list − analog
signals"
^ 437
C7150
Display of the phase input
signals in the InNeg function
block (signal inversion)
^ 313
−2147483647
{1}
2147483647
1 InNeg−PhiV
InNeg−PhiIn1
2 InNeg−PhiV
InNeg−PhiIn2
C7151
Selection of the phase input
signals for the InNeg function
block (signal inversion)
^ 313
1 InNeg−Phi
1000
FIXED 0 (not assigned)
Source for InNeg−PhiIn1
2 InNeg−Phi
1000
FIXED 0 (not assigned)
Source for InNeg−PhiIn2
For possible signals see "selection list − phase
signals"
^ 440
