6.13 Controller enable (CINH = 0)
The controller will only be enabled internally if no signal sources relevant for the controller
inhibit (CINH) are activated (i.e. CINH−signal sources = 0).
The following table shows the signal sources for controller enable:
Source for controller
inhibit Controller
inhibit Controller
enable Note
Terminal X6/SI1 0 ... +4 V
(LOW level) +13 ... +30 V
(HIGH level) For controller enable, X6/SI1 has to be
= HIGH and X6/SI2 = HIGH.
Terminal X6/SI2 0 ... +4 V
(LOW level) +13 ... +30 V
(HIGH level)
C0040 C0040 = 0 C0040 = 1
Operating
module/keypad s key u key Inhibiting with s key is only possible if
the s key is assigned with "CINH" via
C0469.
Fault l In case of TRIP
l In case of
message
l No TRIP/message
active
l TRIP reset
For check see ^ 232.
Control word −
system bus (CAN),
C0135 C0135/bit 9 = 1 C0135/bit 9 = 0 GDC function keys:
l key (controller enable/start)
l key (controller inhibit/stop)
Fieldbus module See Operating Instructions of the corresponding fieldbus module.
)
Note!
All signal sources act like a series connection of switches which are
independent of each other.
