For possible signals see "selection list − digital
signals"
^ 428
C7430
Display of the current signal
states on the analog input of the
"Speed" function block
−32768
(= −100 %)
{1}
32767
(= 100 %)
1 Speed−an
Speed setpoint
(SPEED−NSET.NSet)
^ 326
2 Speed−an
Additional speed setpoint
(SPEED−NSET.NAdd)
3 Speed−an
Lower torque limit
(SPEED-MCTRL.negLoMLim)
^ 332
4 Speed−an
Upper torque limit
(SPEED-MCTRL.HiMLim)
5 Speed−an
Additional torque setpoint
(SPEED-MCTRL.MAdd)
6 Speed−an
Manual field weakening
(SPEED−MCTRL.FldWeak)
7 Speed−an
Manual adaptation of the
proportional gain of the speed
controller
(SPEED−MCTRL.NAdapt)
8 Speed−an
Manual adaptation of the
integral−action component of the
speed controller
(SPEED−MCTRL.ISet)
9 Speed−an
Speed threshold for the motor
holding brake
(SPEED-BRK.SpeedThreshold)
^ 340
10 Speed−an
Direction of torque created by
the drive against the motor
holding brake (SPEED−BRK.Sign)
11 Speed−an
Manual adaptation of the phase
controller (SPEED−MCTRL.PAdapt)
^ 332
12 Speed−an
Limit value for influencing the
phase controller
(SPEED−MCTRL.PosLim)
13 Speed−an
Lower speed limit for speed
limitation
(SPEED−MCTRL.NStartMLim)
