Monitoring functions
Configuring monitoring functions
Motor temperature sensor monitoring (Sd6)
l
219
EDBCSXS064 EN 4.0
9.3.15
Motor temperature sensor monitoring (Sd6)
Fault message
Monitoring function
System variable
Possible response
TRIP
Messag
e
Warnin
g
Off
086
Sd6
Motor temperature sensor
fault
MCTRL_bSensorFault_b
ь
ь
·
· Default setting
üSetting possible
This monitoring function checks whether the motor temperature sensor supplies values
within the measuring range of −50 ... +250 °C. If the values are outside this measuring
range, monitoring is activated.
The response is set via C0594.
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0594 MONIT SD6
3
Fault response − monitoring
KTY sensor for the motor
temperature.
"SensorFault" (Sd6)
^ 219
0
TRIP
2
Warning
3
Off
