11 entry of machine parameters, Commissioning – Lenze ECSCSxxx User Manual
Page 141

Commissioning
Entry of machine parameters
l
141
EDBCSXS064 EN 4.0
6.11
Entry of machine parameters
In the GDC the codes for machine parameters, like for example maximum speed and ramp
times can be found in the parameter menu under
ƒ
Short setup
W Speed (for speed control).
ƒ
Short setup
W Torque (for torque control).
)
Note!
Detailed information concerning the possible settings can be gathered from
the function block descriptions:
ƒ
Function block "Speed":
^ 318
ƒ
Function block "Torque":
^ 343
ECSXA305
Fig. 6−17
GDC view: short setup of the speed control ("Speed")
