Commissioning
Configuring the digital inputs and outputs
Change of the terminal assignment
l
125
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
For possible signals see "selection list − digital
signals"
^ 428
[C7511]
Selection of the signal source for
the digital input signals of the
"Torque" function block
1 TorqueIn−dig
1000
0 (FALSE, not assigned)
CW rotation (TORQUE−RLQ.Cw)
^ 350
2 TorqueIn−dig
1000
0 (FALSE, not assigned)
CCW rotation
(TORQUE−RLQ.CCw)
3 TorqueIn−dig
1000
0 (FALSE, not assigned)
Setting of the torque setpoint
integrator to 0 along the
adjusted ramps
(TORQUE−NSET.Rfg0)
^ 351
4 TorqueIn−dig
1000
0 (FALSE, not assigned)
Activation of the motor holding
brake (TORQUE−BRK.SetBrake)
^ 360
5 TorqueIn−dig
1000
0 (FALSE, not assigned)
Setting of quick stop
(TORQUE−QSP.Set1)
^ 354
6 TorqueIn−dig
1000
0 (FALSE, not assigned)
Setting of quick stop
(TORQUE−QSP.Set2)
7 TorqueIn−dig
1000
0 (FALSE, not assigned)
Source for the integral−action
component of the controller
(TORQUE−MCTRL.ILoad)
8 TorqueIn−dig
1000
0 (FALSE, not assigned)
Keeping (freezing) the torque
setpoint integrator to the current
value (TORQUE-NSET.RfgStop)
9 TorqueIn−dig
1000
0 (FALSE, not assigned)
Inversion of additional torque
setpoint (TORQUE−MAddInv)
For possible signals see "selection list − digital
signals"
^ 428
