Function library
OutNeg
l
316
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C7230
Display of the analog input
signals in the OutNeg function
block (signal inversion)
^ 315
−32768
(= −199.9 %)
{1}
32767
(= 199.9 %)
1 OutNeg−AnV
OutNeg−AnIn1
2 OutNeg−AnV
OutNeg−AnIn2
C7231
Selection of the analog input
signals for the OutNeg function
block (signal inversion)
^ 315
1 OutNeg−An
1000
FIXED 0 % (not assigned)
Source for OutNeg−AnIn1
2 OutNeg−An
1000
FIXED 0 % (not assigned)
Source for OutNeg−AnIn2
For possible signals see "selection list − analog
signals"
^ 437
C7250
Display of the phase input
signals in the OutNeg function
block (signal inversion)
^ 315
−2147483647
{1}
2147483647
1 OutNeg−PhiV
OutNeg−PhiIn1
2 OutNeg−PhiV
OutNeg−PhiIn2
C7251
Selection of the phase input
signals for the OutNeg function
block (signal inversion)
^ 315
1 OutNeg−Phi
1000
FIXED 0 (not assigned)
Source for OutNeg−PhiIn1
2 OutNeg−Phi
1000
FIXED 0 (not assigned)
Source for OutNeg−PhiIn2
For possible signals see "selection list − phase
signals"
^ 440
