Appendix
Code table
l
424
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
[C7431]
Selection of the signal source for
the analog input signals of the
"Speed" function block
1 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Speed setpoint
(SPEED−NSET.NSet)
^ 326
2 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Additional speed setpoint
(SPEED−NSET.NAdd)
3 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Lower torque limit
(SPEED-MCTRL.negLoMLim)
^ 332
4 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Upper torque limit
(SPEED-MCTRL.HiMLim)
5 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Additional torque setpoint
(SPEED-MCTRL.MAdd)
6 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Manual field weakening
(SPEED−MCTRL.FldWeak)
7 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Manual adaptation of the
proportional gain of the speed
controller
(SPEED−MCTRL.NAdapt)
8 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Manual adaptation of the
Integral−action component of the
speed controller
(SPEED−MCTRL.ISet)
9 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Speed threshold for the motor
holding brake
(SPEED-BRK.SpeedThreshold)
^ 340
10 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Direction of torque created by
the drive against the motor
holding brake (SPEED−BRK.Sign)
11 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Manual adaptation of the phase
controller (SPEED−MCTRL.PAdapt)
^ 332
12 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Limit value for influencing the
phase controller
(SPEED−MCTRL.PosLim)
13 SpeedIn−anl
1000
FIXED 0 % (not assigned)
Lower speed limit for speed
limitation
(SPEED−MCTRL.NStartMLim)
For possible signals see "selection list − analog
signals"
^ 437
C7450 Speed−phi
Display of the setpoint for the
phase controller in the "Speed"
function block (speed
controlSPEED−MCTRL.PosSet)
^ 332
−2147483647
{1}
2147483647
[C7451] SpeedIn−phi
1000
Setpoint for the phase controller
in the "Speed" function block
(SPEED−MCTRL.PosSet)
^ 332
FIXED 0 (not assigned)
For possible signals see "selection list − phase
signals"
^ 440
