Appendix – Lenze ECSCSxxx User Manual
Page 413

Appendix
Code table
l
413
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C6155 AIF2PdoMap
0
Assignment of the 8 byte user
data of the AIF2Out function
block to the fieldbus module
^ 258
0
W0=Int W1=Int
Byte 1, byte 2 = AIF2Out−W0
Byte 3, byte 4 = AIF2Out−W1
Byte 5, byte 6 = AIF2Out−W2
Byte 7, byte 8 = AIF2Out−W3
1
W0 / W1=Dint
Byte 1, byte 2 = AIF2Out−W0/W1
Byte 3, byte 4 = AIF2Out−W0/W1
Byte 5, byte 6 = AIF2Out−W2
Byte 7, byte 8 = AIF2Out−W3
C6156 AIF3PdoMap
0
Assignment of the 8 byte user
data of the AIF3Out function
block to the fieldbus module
^ 263
0
W0=Int W1=Int
Byte 1, byte 2 = AIF3Out−W0
Byte 3, byte 4 = AIF3Out−W1
Byte 5, byte 6 = AIF3Out−W2
Byte 7, byte 8 = AIF3Out−W3
1
W0 / W1=Dint
Byte 1, byte 2 = AIF3Out−W0/W1
Byte 3, byte 4 = AIF3Out−W0/W1
Byte 5, byte 6 = AIF3Out−W2
Byte 7, byte 8 = AIF3Out−W3
C6210
Display of the digital output
signals to the MotionBus (CAN)
0 (= FALSE)
1 (= TRUE)
1 CAN−DigOut
CAN1Out−Bit0 (bit 0)
^ 276
2 CAN−DigOut
CAN1Out−Bit1 (bit 1)
3 CAN−DigOut
CAN1Out−Bit2 (bit 2)
4 CAN−DigOut
CAN1Out−Bit3 (bit 3)
5 CAN−DigOut
CAN1Out−Bit4 (bit 4)
6 CAN−DigOut
CAN1Out−Bit5 (bit 5)
7 CAN−DigOut
CAN1Out−Bit6 (bit 6)
8 CAN−DigOut
CAN1Out−Bit7 (bit 7)
9 CAN−DigOut
CAN1Out−Bit8 (bit 8)
10 CAN−DigOut
CAN1Out−Bit9 (bit 9)
11 CAN−DigOut
CAN1Out−Bit10 (bit 10)
12 CAN−DigOut
CAN1Out−Bit11 (bit 11)
13 CAN−DigOut
CAN1Out−Bit12 (bit 12)
14 CAN−DigOut
CAN1Out−Bit13 (bit 13)
15 CAN−DigOut
CAN1Out−Bit14 (bit 14)
16 CAN−DigOut
CAN1Out−Bit15 (bit 15)
17 CAN−DigOut
CANSync−ResetSyncForInterpolat
ord
^ 267
18 CAN−DigOut
CAN−ResetNode
^ 179
19 CAN−DigOut
CAN−TxCan2Synchronized
20 CAN−DigOut
CAN−TxCan3Synchronized
