Function library
DCTRL
l
295
EDBCSXS064 EN 4.0
Codes
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0135 Control word
0
System control word DCTRL
0
{1}
65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0
Not assigned
Bit 1
Not assigned
Bit 2
Not assigned
Bit 3
Quick stop (QSP)
Bit 4
Not assigned
Bit 5
Not assigned
Bit 6
Not assigned
Bit 7
Not assigned
Bit 8
Operation inhibit (DISABLE)
Bit 9
Controller inhibit (CINH)
Bit 10
TRIP−SET
Bit 11
TRIP−RESET
Bit 12
Not assigned
Bit 13
Not assigned
Bit 14
Not assigned
Bit 15
Not assigned
C0136
Control words
Hexadecimal value is bit−coded.
Read only
1 CTRLWORD
0
{hex}
FFFF Control word C0135
2 CTRLWORD
CAN control word
3 CTRLWORD
AIF control word
C0150 Status word
0
Device status word for
networking via automation
interface (AIF)
Read only
^ 299
0
{1}
65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0
Not assigned
Bit 1
Pulse inhibit (IMP)
Bit2
Not assigned
Bit3
Not assigned
Bit4
Not assigned
Bit5
Not assigned
Bit 6
n = 0
Bit 7
Controller inhibit (CINH)
Bit 8
Device status bit 1
Bit 9
Device status bit 2
Bit10
Device status bit 3
Bit11
Device status bit 4
Bit12
Warning
Bit13
Message
Bit14
Not assigned
Bit15
Not assigned
