Appendix – Lenze ECSCSxxx User Manual
Page 411

Appendix
Code table
l
411
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C6130
Display of the analog output
signals to the fieldbus module
−32768
{1}
32767
1 AIF−AnOut
Output word AIF1Out−DctrlStat
^ 251
2 AIF−AnOut
Output word AIF1Out−W1
3 AIF−AnOut
Output word AIF1Out−W2
4 AIF−AnOut
Output word AIF1Out−W3
5 AIF−AnOut
Output word AIF2Out−W0
^ 258
6 AIF−AnOut
Output word AIF2Out−W1
7 AIF−AnOut
Output word AIF2Out−W2
8 AIF−AnOut
Output word AIF2Out−W3
9 AIF−AnOut
Output word AIF3Out−W0
^ 263
10 AIF−AnOut
Output word AIF3Out−W1
11 AIF−AnOut
Output word AIF3Out−W2
12 AIF−AnOut
Output word AIF3Out−W3
[C6131]
Selection of the analog output
signals to the fieldbus module
1 AIF1Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF1Out−DctrlStat
^ 251
2 AIF1Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF1Out−W1
3 AIF1Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF1Out−W2
4 AIF1Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF1Out−W3
5 AIF2Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF2Out−W0
^ 258
6 AIF2Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF2Out−W1
7 AIF2Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF2Out−W2
8 AIF2Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF2Out−W3
9 AIF3Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF3Out−W0
^ 263
10 AIF3Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF3Out−W1
11 AIF3Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF3Out−W2
12 AIF3Out−anl
1000
FIXED 0 % (not assigned)
Source for output word
AIF3Out−W3
For possible signals see "selection list − analog
signals"
^ 437
C6150
Display of the phase output
signals to the fieldbus module
−2147483647
{1}
2147483647
1 AIF−PhiOut
Output double word
AIF1Out-W2/W3
^ 251
2 AIF−PhiOut
Output double word
AIF2Out-W0/W1
^ 258
3 AIF−PhiOut
Output double word
AIF3Out-W0/W1
^ 263
