Commissioning
Optimising the drive behaviour after start
Speed controller adjustment
l
155
EDBCSXS064 EN 4.0
Parameter setting
ƒ
Set the proportional gain (V
pn
) via C0070:
– Enter approx. 50 % of the speed setpoint (100 % = 16384 = n
max
).
– Increase C0070 until the drive becomes instable (pay attention to engine noises).
– Reduce C0070 until the drive runs stable again.
– Reduce C0070 to approx. half the value.
)
Note!
For speed control ("Speed"):
The proportional gain (V
p
) can be altered via SPEED−MCTRL.NAdapt (C7431/7):
ƒ
V
p
= SPEED−MCTRL.NAdapt[%] x C0070
ƒ
If SPEED−MCTRL.NAdapt is not assigned, the following applies: V
p
= 100 %,
C0070 = C0070
For torque control ("Torque"):
The proportional gain (V
p
) can be altered via TORQUE−MCTRL.NAdapt
(C7531/7):
ƒ
V
p
= TORQUE−MCTRL.NAdapt[%] x C0070
ƒ
If TORQUE−MCTRL.NAdap is not assigned, the following applies: V
p
= 100 %,
C0070 = C0070
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0070 Vp speedCTRL
3.0
Proportional gain of speed
controller (V
pn
)
^ 154
0.00
{ 0.01}
127.99
ƒ
The reset time (T
nn
) is set via C0071:
– Reduce C0071 until the drive becomes instable (pay attention to engine noises).
– Increase C0071 until the drive runs stable again.
– Increase C0071 to approx. the double value.
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0071 Tn speedCTRL
24.0
Reset time − speed controller
(T
nn
)
^ 154
1.0
{0.5 ms}
6000.0
