C7410
Display of the current signal
states on the digital inputs of the
"Speed" function block
0 (= FALSE)
1 (= TRUE)
1 Speed−dig
CW rotation (SPEED−RLQ.Cw)
^ 325
2 Speed−dig
CCW rotation (SPEED−RLQ.CCw)
3 Speed−dig
Selection of the fixed speeds
(SPEED−NSET.Jog1)saved in
C0039
^ 326
4 Speed−dig
Selection of the fixed speeds
(SPEED−NSET.Jog2)saved in
C0039
5 Speed−dig
Selection of the fixed speeds
(SPEED−NSET.Jog4)saved in
C0039
6 Speed−dig
Selection of the fixed speeds
(SPEED−NSET.Jog8)saved in
C0039
7 Speed−dig
Setting of the speed setpoint
integrator to "0" along the
adjusted ramps
(SPEED−NSET.Rfg0)
^ 326
8 Speed−dig
Inversion of additional speed
setpoint (SPEED−NAddInv)
9 Speed−dig
Keeping (freezing) the speed
setpoint integrator to the actual
value (SPEED-NSET.RfgStop)
10 Speed−dig
Activation of the motor holding
brake (SPEED−BRK.SetBrake)
^ 340
11 Speed−dig
Switching of speed/torque
(SPEED−MCTRL.NMSwt)
^ 332
12 Speed−dig
Source for the integral−action
component of the speed
controller (SPEED−MCTRL.ILoad)
13 Speed−dig
Selection of the acceleration and
deceleration times stored in
C0101 and C0103
(SPEED−NSET.TI1)
^ 326
14 Speed−dig
Selection of the acceleration and
deceleration times stored in
C0101 and C0103
(SPEED−NSET.TI2)
15 Speed−dig
Selection of the acceleration and
deceleration times stored in
C0101 and C0103
(SPEED−NSET.TI4)
16 Speed−dig
Selection of the acceleration and
deceleration times stored in
C0101 and C0103
(SPEED−NSET.TI8)
17 Speed−dig
Setting of quick stop
(SPEED−QSP.Set1)
^ 332
18 Speed−dig
Setting of quick stop
(SPEED−QSP.Set2)
19 Speed−dig
Activation of phase controller
(SPEED-MCTRL.PosOn)
20 Speed−dig
Inversion of additional torque
setpoint (SPEED−MAddInv)
