Electrical installation
Standard devices in the power range 75 ... 90 kW
Mains choke/mains filter assignment
l
194
EDKVF9333V DE/EN/FR 7.1
Installation to UL
Supply conditions
Range
Description
Fuses
l
Only according to UL 248
l
Mains short−circuit current up to 10000 A
rms
: All classes permissible
l
Mains short−circuit current up to 50000 A
rms
: Only classes "J", "T" or "R" permissible
Cables
l
Only in accordance with UL
l
The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Observe all national and regional regulations!
Operation at rated power
9300
Rated fuse current
Cable cross−section
Fuse
L1, L2, L3, PE
Type
[A]
[AWG]
Operation with mains choke/mains filter
EVF9332−xV
175
2/0
EVF9333−xV
200
3/0
5.7.4
Mains choke/mains filter assignment
Operation at rated power
9300
Mains choke
Interference voltage category according to EN 61800−3 and motor cable length
Component
Component
Type
C2
max. [m]
C1
max. [m]
EVF9332−xV
ELN3−0022H130
EZN3A0022H150
25
E82ZN75334B230
10
E82ZN75334B230
50
EZN3B0022H150
50
EVF9333−xV
ELN3−0017H170
EZN3A0017H200
25
E82ZN90334B230
10
E82ZN90334B230
50
EZN3B0017H200
50
Operation with increased rated power
9300
Mains choke
Interference voltage category according to EN 61800−3 and motor cable length
Component
Component
Type
C2
max. [m]
C1
max. [m]
EVF9332−xV
ELN3−0017H170
EZN3A0017H200
25
E82ZN90334B230
10
E82ZN90334B230
50
EZN3B0017H200
50
EVF9333−xV
ELN3−0014H200
EZN3A0015H230
25
EZN3B0015H230
50
EZN3A0017H200
25
EZN3B0017H200
50
