Mechanical installation
Standard devices with a power of 45 kW
Thermally separated mounting (push−through technique)
l
150
EDKVF9333V DE/EN/FR 7.1
4.3.3
Thermally separated mounting (push−through technique)
For mounting in push−through technique, the drive controller of type EVF93xx−EV must be
used. In addition, the mounting set EJ0010 for push−through technique is required.
Dimensions
d2
d2
d2
d
b
g
a1
a
d1
b1
h
h
c1
c2
c3
c4
e
e1
L
9300vec117
Fig. 4−8
Dimensions for thermally separated mounting 45 kW
9300 vector
Dimensions [mm]
Type
a
a1
b
b1
c1
c2
c3
c4
d
d1
d2
e
1)
e1
g
h
EVF9330−EV
373
340
543
510
45
137.5
217.5
310
525
45
145
285
163.5
7
9
1)
For a fieldbus module plugged onto X1, consider mounting space for connecting cables
Mounting cutout in control cabinet
9300 vector
Dimensions [mm]
Type
Width
Height
EVF9330−EV
320
492
