Lenze EVF9333 - Manual (Page 177)

Electrical installation
Standard devices in the power range 15 ... 30 kW
Mains choke/mains filter assignment
5
l
177 EDKVF9333V DE/EN/FR 7.1
Installation to UL
Supply conditions
Range Description
Fuses l Only according to UL 248
l Mains short−circuit current up to 5000 A
rms
: All classes permissible
l Mains short−circuit current up to 50000 A
rms
: Only classes "J", "T" or "R" permissible
Cables l Only in accordance with UL
l The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Observe all national and regional regulations!
Operation at rated power
9300 Rated fuse current Cable cross−section
Fuse L1, L2, L3, PE
Type [A] [AWG]
Operation with mains choke/mains filter
EVF9327−xV 35 8
EVF9328−xV 50 6
EVF9329−xV 80 4
5.5.4 Mains choke/mains filter assignment
Operation at rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9327−xV ELN3−0088H035−001 EZN3A0110H030 25 E82ZN22334B230 10
E82ZZ15334B230 1) 10
E82ZN22334B230 50 EZN3B0110H030U 2) 50
E82ZZ15334B230 1) 50
EVF9328−xV ELN3−0075H045 EZN3A0080H042 25 E82ZN22334B230 10
E82ZN22334B230 50 EZN3B0080H042 50
EVF9329−xV ELN3−0055H055 EZN3A0055H060 25 E82ZN30334B230 10
E82ZN30334B230 50 EZN3B0055H060 50
1) RFI filter
2) Footprint filter
Operation with increased rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9327−xV ELN3−0075H045 EZN3A0080H042 25 E82ZN22334B230 10
E82ZN22334B230 50 EZN3B0080H042 50
EVF9328−xV ELN3−0055H055 EZN3A0055H060 25 E82ZN30334B230 10
E82ZN30334B230 50 EZN3B0055H060 50
EVF9329−xV ˘ EZN3B0055H060N003 50 EZN3B0055H060N003 50
