8 Programming
98
8.6.4 External text
A signal at one logic input (external contact)
can prompt the recorder to print a text/
commentary which is programmed here.

Extra Code 259 is required.

Section 7.7
Display Edit Selection/input with keys Edit Continue with
EXTERNAL TEXT
E
2 EXTERNAL TEXT
Select text number:
1 — 8
h
,
R E 
2

2 2 CONTACT:
LOG.INPUT 3
Select logic input:
OFF
LOG.INPUT 1
LOG.INPUT 2
LOG.INPUT 3
LOG.INPUT 4
...
LOG.INPUT 8
h
,
R E
OFF:
h
forwards
R
backwards
otherwise:

3

3 2 TEXT: _ _ _ _ _ _ _ _ _ _
Input text
(16 characters)
h
,
R
,
l
,
r
,
S
E h
forwards
R
backwards
