12 Appendix
12.1 Technical Data
Analogue inputs
(measurement channels)
Measurement time
240 msec for all three channels
Input filter
digital second-order filter
filter time constant adjustable 0 — 10.0sec.
Thermocouples
shortest span: 100°C
Measurement accuracy:
±0.1% referred to range limits. On Type J
this applies only from –200 °C upwards, on
Type U and T only from –150 °C, on Type K
only from –80 °C and on Types E und N only
from –100 °C upwards.
shortest span: 500 °C
Measurement accuracy:
±0.15% referred to range limits. On Type B
this applies only from 400 °C upwards, on
Types S and R only from 0 °C upwards.
Within the range limits the start and end of
range can be freely programmed in 0.1°C
steps.
Type Range limits
Fe-Con L
Fe-Con J
Cu-Con U
Cu-Con T
NiCr-Ni K
NiCr-Con E
NiCrSi-NiSi N –200 +900°C
–210 +1200°C
–200 +600°C
–270 +400°C
–270 +1372°C
–270 +1000°C
–270 +1300°C
Type Range limits
Pt10Rh-Pt S
Pt13Rh-Pt R
Pt30Rh-Pt6Rh B –50 +1768°C
–50 +1768°C
0 +1820°C
Cold junction
internal: Pt100
Accuracy of internal cold junction: ±1.0 °C
external: cold junction thermostat
The cold junction temperature is set in the
setup program to a constant value between
–20 and +100 °C.
external: Pt100 in 3-wire circuit
Resistance thermometers
shortest span: 15 °C
Measurement accuracy:
Within the range limits the start and end of
range can be freely programmed in 0.1°C
steps.
lead resistance:
3-wire circuit 30
Ω
max. per lead
2-wire circuit 15
Ω
max. per lead
measurement current:
0.4mA on Pt100 und Ni100
0.05mA on Pt 500 und Pt1000
Resistance transmitters
with 3-wire connection
3.9 k
Ω
max.
min.span: 6
Ω
Type Range limits Linearisation
Pt100
Pt100
Pt500
Pt1000
Ni100 –200 +850°C
–200 +649°C
–200 +850°C
–200 +850°C
–60 +180°C
IEC
JIS
IEC
IEC
Range 2-wire
3-wire 4-wire
–200 +100°C
–200 +850°C
±0.4°C
±0.8 °C ±0.4°C
±0.5 °C
