8 Programming
77
8.4.7 Presentation range (offset)
Defines the range on the chart on which a
trace is to be recorded. Either the entire
width of 100 mm or a strip can be selected
for the display. Sets the start and end of the
trace on the chart. The input is made in mm
steps.
Display Edit Selection/input with keys Enter Continue with
OFFSET
E
2 OFFSET
Select recording channel
h
,
R E 
2

2 2 LOW:
20 mm
Input start of offset
h
,
R
,
l
,
r
E
Check:
0
≤
start
≤
99

3

3 2 HIGH:
060 mm
Input end of offset
h
,
R
,
l
,
r
E
Check:
start
<
end,
end
≤
100
h
forwards
R
backwards
