8 Programming
93
8.6.1 Relay output
The external relay module ER8 is connected
to the recorder via a serial interface. It adds
8 switching outputs to the recorder. The
channels which are recorded can be freely
assigned to relays 1 to 8. The limit value be-
longing to the relays is set at the parameter
level. (
v Section 8.3.5).
Texts TEXT L and TEXT H, which can be
freely configured, report the limit transitions.
(
v Section 7.7).
For lk7 and lk8
v Section 10.3

Extra Code 259 is required.

Accessory “External relay module
ER8” is required.
Display Edit Selection/input with keys Enter Continue with
RELAY-OUTPUTS
E
RELAY: 3
Select relay:
1 — 8
h
,
R E 
2

2 REL3 STATE: ON
Input relay status:
OFF, ON
h
,
R E
OFF:
h
forwards
R
backwards
ON:

3

3
(ON)
REL3 CHANNEL: 2
Select channel
belonging to relay :
1 — 3
h
,
R E 
4

4 2 REL3 HYST.L:
x.xxx
Input differential left of
the limit
h
,
R
,
l
,
r
,
S
E 
5
