8 Programming
69
Display Edit Selection/input with keys Enter Continue with
(Continued:
INPUT)

7
(VOLTAGE)
1 CHARACT.: linear
linear
Pt 100
(–200 to +850°C)
Pt 100 (–200 to +649°C, JIS)
Pt 500 (–200 to +850°C)
Pt 1000 (–200 to +850°C)
Ni 100 (–60 to +180°C)
L (–200 to +900°C)
J (–210 to +1200°C)
U (–200 to +600°C)
T (–270 to +400°C)
K (–270 to +1372°C)
E (–270 to +1000°C)
N (–270 to +1300°C)
S (–50 to +1768°C)
R (–50 to +1768°C)
B (0—1820°C)
X1 (customized lin. 1)
X2 (customized lin. 2)
h
,
R E
customized
X1
1
or X2
1
:

10 (FILTER)
otherwise:

71

71 1 UNIT: mV
mV, V
h
,
R E 
72

72 1 RANGE BEG:
+0.000 mV
Input start of
measurement range
h
,
R
,
l
,
r
,
S
E
Check
range start
(–10.0V
≤
range start
<
10.0V
or 0.0V
<
range start
≤
22.0V)

73

73 1 RANGE END:
+999.0 mV
Input end of
measurement range
h
,
R
,
l
,
r
,
S
E
Check
range end
(–10.0V
≤
range end
<
10.0V
or 0.0V
<
range end
≤
22.0V)
min. span:
5 mV
linear
characteristic:

10 (FILTER)
otherwise:

74
1. If required, gain factors of transmitters must be taken into account when entering the characteristics in the setup program.
