8 Programming
101
8.6.7 External speed
The chart speed changed to when the logic
input which has the function FEED EXTERN
assigned to it is closed.

Extra Code 259 is required.
Display Edit Selection/input with keys Enter Continue with
FEED EXTERN
E
CONTACT: LOG.INPUT 3
Select logic input:
OFF
LOG.INPUT 1
LOG.INPUT 2
LOG.INPUT 3
LOG.INPUT 4
...
LOG.INPUT 8
h
,
R E
OFF:
h
forwards
R
backwards
otherwise:

2

2
(
with
step speed
programming)
FEED EXTERN:
7200 mm/h
Select speed:
0, 5, 10, 20, 60, 120, 240,
300, 360, 600, 720, 1800,
3600, 7200 mm/h
h
,
R E h
forwards
R
backwards

2
(with
continuous
speed
programming)
FEED EXTERN:
0000 mm/h
Set the required chart
speed
value range:
0 — 7200 mm/h
h
,
R
,
l
,
r
E
Check
speed value
h
forwards
R
backwards
