2 Identifying the instrument version
11
2.2 Type designation
The label is affixed to the housing. The in-
strument version can be identified from the
type designation.
The extra Codes are listed in sequence and
separated by a comma.
The voltage of the supply must agree with
the voltage shown on the label.
1. Please specify probe types and measurement
ranges in plain text.
2. This extra code is available in combination with
supply voltage 110—240V AC, not with low supply
voltage. UL approval is not available.
The protection type in the carrying case
corresponds to IP20, outside IP20D.
3. UL approval is not available.
4. Extra codes are listed in sequence and separated
by a comma.
(1) Basic version
706021 LOGOLINE 500d with 1 universal input and text output
706022 LOGOLINE 500d with 2 universal inputs and text output (via channel 1)
706023 LOGOLINE 500d with 3 universal inputs and text output (via channel 1)
(2) Inputs 1 — 3 (programmable)
x x x 8 factory-set
x x x 9 configuration to customer specification 1
(3) Interface
x x x 00 not assigned
x x x 52 RS422, Jbus, Modbus
x x x 53 RS485, Jbus, Modbus
(4) Supply
x x x 22 20—53V AC/DC +0/-0% 48—63Hz
x x x 23 110—240V AC +10/-15% 48—63Hz
(5) Extra codes
x x x 020 lithium battery for RAM buffer (ex-factory)
x x x 021 storage capacitor for RAM buffer (instead of extra code 020)
x x x 259 8 logic inputs, interface for external relay module (ER8),
voltage output 24V 50mA DC
x x x 265 door with lock (IP54)
x x x 266 IP65 seal, wide fixing brackets
x x x 350 universal carrying case TG-35 2
x x x 351 housing with carrying handle 3
(1) (2) (3) (4) (5)
Order code / - - / , ... 4
Order example 706023 / 8 - 00 - 23 / 020
