8 Programming
83
8.5.4 Timed operation
Chart speed which is only valid within the
entered time span.
On reaching the start time, the chart speed
is changed over to the value configured
here.
When the end time has been reached, the
chart speed is switched back to the stand-
ard chart speed.
If start time = end time, the timed operation
is switched off.

Please observe priorities within the
different chart speeds.
v Section 7.5
Display Edit Selection/input with keys Enter Continue with
FEED TIME
E

with
step speed
programming:
FEED TIME:
7200 mm/h
Select speed:
0, 5, 10, 20, 60, 120, 240,
300, 360, 600, 720, 1800,
3600, 7200 mm/h
h
,
R E 
2

with
continuous
speed
programming:
FEED TIME:
0000 mm/h
Set required chart speed,
value range:
0 — 7200 mm/h
h
,
R
,
l
,
r
E
Check:
speed value

2

2 FROM-TO:
21 : 30 06 : 30
h min
Input start time
(seconds = 0 sec)
h
,
R
,
l
,
r
E
Check time

3

3 FROM-TO:
21 : 30 06 : 30
h min
Input end time
(seconds = 0 sec)
h
,
R
,
l
,
r
E
Check time
h
forwards
R
backwards
