7 Text printing
41
7.7 External text, binary-linked
text, relay texts
External text
Eight logic inputs are available for external
texts.
Closing a logic input causes the corre-
sponding text to be printed. Opening the
logic input has no effect.
Binary-linked external text
It is possible to interpret the signals at the
first 4 logic inputs as a binary number and
to assign a text to each binary number. In
this way it is possible to print up to 16 texts.
Following each change of status of these
logic inputs, the text corresponding to the
binary number is printed.
Text printing can be switched off separately
for each of the 16 texts.
Example:
If the state of the logic inputs is the binary
number 1001, then text 9 is printed.
If the first logic input on the right is opened,
the state of the logic inputs is the binary
number 1000. Text 8 is being printed.

Extra Code 259 required.

Section 8.6.4

Section 8.6.5
12:34 Overload
Binary
number Decimal
number/text
0000 0
0001 1
0010 2
0011 3
0100 4
0101 5
0110 6
0111 7
1000 8
1001 9
1010 10
1011 11
1100 12
1101 13
1110 14
1111 15
logic input 4
logic input 1
