8 Programming
82
8.5.3 Speed limit operation
Chart speed on limit operation. It is possible
to change to this chart speed, if the signal
goes above/below the limit values entered
under the parameter LIMIT FEED.

Please observe priorities within the
different chart speeds.
v Section 7.5
Display Edit Selection/input with keys Enter Continue with
FEED LIMIT
E

with
step speed
programming:
FEED LIMIT:
7200 mm/h
Select chart speed:
0, 5, 10, 20, 60, 120, 240,
300, 360, 600, 720, 1800,
3600, 7200 mm/h
h
,
R E h
forwards
R
backwards

with
continuous
speed
programming:
FEED LIMIT:
0000 mm/h
Set required chart speed,
value range:
0 — 7200 mm/h
h
,
R
,
l
,
r
E
Check
speed value
h
forwards
R
backwards
