10 Extra Codes and accessories
112
10.3 External relay module ER8
The external relay module ER8 adds eight
switching outputs to the recorder. The re-
lays are freely assigned to the recorder
channels in the setup program
( Section 10.4).
The limit for each relay is programmed at
the parameter level.
The switching differential about the limit set-
ting can be freely configured in the setup
program. The limit comparator functions
lk7 and lk8 are available

Section 8.3.5

Section 8.6.1

The external relay module ER8 can
only be operated when the Extra
Code 259 is installed.

When the setup connector is
plugged into the recorder all relays
are de-energised.
