1 About this Manual
7
1.2 Arrangement of the
documentation
The documentation for this instrument con-
sists of the following parts:
Operating Manual B 70.6021.0
This Operating Manual is always supplied
with the instrument. It is addressed to the
OEM (original equipment manufacturer)
and to the user with appropriate technical
know-how.
In addition to installation and electrical con-
nection it contains all the information on in-
strument start-up, operation and parameter
setting.
Interface Description B 70.6001.2
This Operating Manual is supplied with the
instrument, if one the interfaces (RS422 or
RS485) has been ordered. It provides infor-
mation on communication with higher-level
(supervisory) systems.
Online help
The online help is part of the setup program.
It is a Windows
1
online help.
1. Microsoft und Windows are registered trade-
marks of the Microsoft Corporation
