10.6 Interface (RS422/RS485)
This interface is intended for communica-
tion with higher-level systems (e.g. bus sys-
tems). It is not the setup interface, which is
used to transfer the data between the setup
program and the pen recorder.
The RS422/RS485 interface is described in
detail in the Operating Manual B 70.6001.2.
