8 Programming
66
Display Edit Selection/input with keys Enter Continue with
(Continued:
INPUT)

4
(THERMO-
COUPLE)
1 CHARACT.:L
L (–200 to +900°C)
J (–210 to +1200°C)
U (–200 to +600°C)
T (–270 to +400°C)
K (–270 to +1372°C)
E (–270 to +1000°C)
N (–270 to +1300°C)
S (–50 to +1768°C)
R (–50 to +1768°C)
B (0 — 1820°C)
X1 (customized lin. 1)
X2 (customized lin. 2)
h
,
R E
customized
X1 or X2:

10 (FILTER)
otherwise:

41

41 1 UNIT: °C
°C, °F
h
,
R E 
42

42 1 RANGE BEG: –200.0 °C
Input start of
measurement range
h
,
R
,
l
,
r
,
S
E
Check
range start
according to
characteristic

43

43 1 RANGE END: +900.0 °C
Input end of
measurement range
h
,
R
,
l
,
r
,
S
E
Check
range end
according to
characteristic
end – start
≥
100°C
S,R,B
≥
500°C

44

44 1 TEMP. COMP:
INTERN Pt 100
INTERN Pt 100
EXTERN Pt 100
EXT. CONST.
h
,
R E
INTERN Pt 100 1 :
EXTERN Pt 100:

10 (FILTER)
EXT. CONST.:

45

45
(only with
EXT.
CONST.)
1 COMP. TEMP.:
+0020. °C
Input cold junction
temperature
(value range:
–20 to +100°C)
h
,
R
,
l
,
r
,
S
E
Check
value range

10 (FILTER)
1. The cold junction temperature of the internal cold junction is measured on channel 1. It is also valid for channels 2 and 3.
If one or more thermocouple inputs are configured with an internal cold junction, a thermocouple with internal cold junction
measurement or external constant cold junction temperature has to be configured for channel 1.
