8 Programming
71
Display Edit Selection/input with keys Enter Continue with
(Continued:
INPUT)

8
(CURRENT)
1 CHARACT.: linear
linear
Pt 100
(–200 to +850°C)
Pt 100 (–200 to +649°C, JIS)
Pt 500 (–200 to +850°C)
Pt 1000 (–200 to +850°C)
Ni 100 (–60 to +180°C)
L (–200 to +900°C)
J (–210 to +1200°C)
U (–200 to +600°C)
T (–270 to +400°C)
K (–270 to +1372°C)
E (–270 to +1000°C)
N (–270 to +1300°C)
S (–50 to +1768°C)
R (–50 to +1768°C)
B (0 — 1820°C)
X1 (customized lin. 1)
X2 (customized lin. 2)
h
,
R E
customized.
X1
1
or X2
1
:

10 (FILTER)
otherwise:

81

81 1 RANGE BEG:
+0.000 mA
Input start of
measurement range
h
,
R
,
l
,
r
,
S
E
Check
range start
(–20,5mA
≤
range start
<
20.5 mA
or 0.0mA
≤
range start
≤
45.0 mA
or
–4,0mA
≤
range start
≤
21.0 mA)

82
1. Gain factors of transmitters must, if required, be taken into account when entering the characteristics in the setup program.
