6 Preparation
28
Entering parameters
Where there are no further sub-parameters,
E
transfers all the data of the parame-
ter to the memory.
Aborting programming
Programming can be aborted within a pa-
rameter by pressing the key
e
.
Error messages during programming
If there are error messages during program-
ming due to incorrect inputs, these have to
be acknowledged with
E
before pro-
gramming can be repeated.

If the last sub-parameter has not yet
been entered, the parameter data
which have already been edited are
discarded. The old sub-parameters
are retained.
Key functions
e
- Chart fast forward when
recording is stopped
(in basic status)
- Aborting parameter input
(Exit)
- Level change backwards
S
- Start/Stop recording
- Decimal place selection
during value input
- For text input:
rapid character selection
(jump to “ ”,“0”,“A”,“a”,
“°”, “²”,“А”,“а”)
F
- Function key
for special function
(hold down at least 4 sec)
factory setting:
scale printout
l
,
r
- Cursor left/right
(select digit)
l
+
r
- Deactivate/activate
display of status/error
messages
h
,
R
- Select display:
- date and time
- channel measurements
- bargraph
- system states
- Parameter selection
- Channel selection
- Value selection
from value table
- Increment/ decrement/
current digit
h
+
R
- Level change forwards
E
- Initiate parameter input
- Enter input
- Acknowledge
error message
- Activate/ deactivate
static display
(in basic status)
