12 Appendix
General Data
Zero adjustment
self-compensating system using Hall sensors
Recording system
drive by stepping motor
sensitivity:
0.2 % or better referred to 100 mm recording
width
reproducibility:
0.25 % or better referred to 100 mm
recording width
response time:
1sec referred to 100 mm recording width
Indication and recording accuracy
Class 0.5 referred to range limits and basic
ranges
Writing system
fibre pen
Colour sequence
channel 1: blue
channel 2: red
channel 3: green
Ink capacity
sufficient for approx.1000 m trace;
on channel 1 depending on text printing
Pen offset
2(4) mm between pen 1 and pen 2(3).
Can be corrected by pen offset compensation
Overrun/underrun
electronic limitation to 0 — 100 mm writing
width
Chart speed
programmable from keys:
0, 5, 10, 20, 60, 120, 240, 300, 360, 600, 720,
1800, 3600, 7200mm/h
or freely programmable in 1mm/h steps
Chart drive
by stepping motor and gearbox
Chart cassette
cassette for 16 m or 32 m roll chart or 16 m
fanfold chart, with tear-off edge and electron-
ic chart end switch.
Chart
roll or fanfold chart to DIN 16 230
overall width:
120 mm
writing width: 100 mm
pin spacing: 110 mm
visible chart length
roll chart:
60 mm
fanfold chart: 30 — 60 mm
overall length
roll chart:
16 m or 32 m
fanfold chart: 16 m
Supply
AC: 93 — 263 V 48 — 63 Hz
or
DC/AC: 20 — 53V 48—63 Hz
Test voltages (type test)
To EN 61 010, Part 1 (March 1994)
overvoltage Category II,
pollution Grade 2
supply against input circuit:
on AC supply
3.7 kV 50Hz, 1min,
on DC/AC supply
510V 50Hz, 1min
supply against case
(protective earth):
on AC supply
2.3 kV 50Hz, 1min,
on DC/AC supply
510 V 50Hz, 1min
inputs agains inputs and inputs against
case:
510V 50Hz, 1min
isolation between analogue inputs up to
30V AC/50 V DC
Supply voltage error
less than 0.1% of range span
