7 Text printing
36
7.4 Scaling
The scaling can be printed in two ways:
cyclic: for each channel at a configured
spacing
triggered: for all channels on pressing the
(
F
key (hold down for at least 4
sec) or by closing one of the log-
ic inputs.
Cyclic scaling print-out
Spacing which can be selected:
- 30 cm approx.
- 60 cm approx.
- 90 cm approx.
- off
The lowest line shows the channel number,
the corresponding pen colour, the pro-
grammed channel designation and the unit
of the measured value.
If the range 0 —100mm has not been al-
tered by offset, the next line shows the scale
values for 0%, 50% und 100%. If the range
has been restricted, this line contains marks
for the start and the end of the range. The
corresponding numbers are printed in the
next line.
The limit marks for the current channel are
printed in the top line.
