98
• Data
• Reference Data (available to read out/write in)
Note: Write in “0” for unused bit. Never write in data for the reserved register.
• Simultaneous Broadcasting Data (available only for write in)
Bit signals not defined as the broadcast operation signals are used as the local station
data signals.
Register No. bit Description
0000H Reserved
0001H
0 Run command 1 : Run 0 : Stop
1 Reverse run 1 : Reverse run 0 : Forward run
2 External fault 1 : Fault (EFO)
3 Fault reset 1 : Reset command
4 Multi-function input reference 1 (Function selected by n050)
5 Multi-function input reference 2 (Function selected by n051)
6 Multi-function input reference 3 (Function selected by n052)
7 Multi-function input reference 4 (Function selected by n053)
8 Multi-function input reference 5 (Function selected by n054)
9 Multi-function input reference 6 (Function selected by n055)
A Multi-function input reference 7 (Function selected by n056)
B-F (Not used)
0002H Frequency reference (unit : n152)
0003H V/f gain (1000/100%) Setting range : 2.0% ~ 200.0%
0004H-
0008H
Reserved
0009H
0
Multi-function output reference 1
(Effective when n057=18)
( 1 : MA “ON” 0 = MA “OFF” )
1
Multi-function output reference 2
(Effective when n058=18) ( 1 : P1 “ON” 0 = MA “OFF” )
2
Multi-function output reference 3
(Effective when n059=18) ( 1 : P2 “ON” 0 = MA “OFF” )
3-F (Not used)
000AH-
001FH
Reserved
Register No. bit Description
0001H
0 Run command 1 : Run 0 : Stop
1 Reverse run 1 : Reverse run 0 : Forward run
2 (Not used)
3 (Not used)
4 External fault 1 : Fault (EFO)
5 Fault reset 1 : Fault reset command
6-F (Not used)
0002H
30000/100% fixed unit
(Data is converted into 0.01 Hz inside the inverter, and fractions are rounded off.)
