Register No.
bit
Description
002AH
A
larm
Cont
ent
s
0
Operator stop (STP)
1
Sequence error (SER)
2
FWD - REV command simulation input (EF)
3
External baseblock (BB)
4
Overtorque detection (OL3)
5
Cooling fin overheat (OH)
6
Main circuit overvoltage (OV)
7
Main circuit undervoltage
8
Cooling fan fault (FAN)
9
Communication error
A
Option card communication error (BUS)
B
Not used
C
Inverter overheat prediction (OH3)
D
PID feedback loss (FBL)
E
Emergency stop (STP)
F
Communication waiting (CALL)
002BH
S
equ
enc
e i
n
put
0
Terminal S1
1 : Closed O : Open
1
Terminal S2
1 : Closed O : Open
2
Terminal S3
1 : Closed O : Open
3
Terminal S4
1 : Closed O : Open
4
Terminal S5
1 : Closed O : Open
5
Terminal S6
1 : Closed O : Open
6
Terminal S7
1 : Closed O : Open
7-F
(Not Used)
002CH
In
v
e
rt
er s
tat
us
0
Run
1 : Run
1
Zero - speed
1 : Zero - speed
2
Frequency agreed
1 : Agreed
3
Minor fault (Alarm is indicated)
4
Frequency detection 1
1: Output frequency
≤
(n095)
5
Frequency detection 2
1
:
Output frequency
≥
(n095)
6
Inverter operation ready
1 : Ready
7
Undervoltage detection
1 : Under Voltage detection
8
Baseblock
1 : Inverter output base block
9
Frequency reference mode
1 : Other than communications
0 : Communications
A
Run command mode
1 : Other than communications
0 : Communications
B
Overtorque detection
1 : Detection or overtorque fault
C
(Not used)
D
Fault restart
E
Fault (Including MEMOBUS communications timeover)
1 : Fault
F
MEMOBUS communications timeover 1 : Timeover
002DH
0
MA “ON”
1 : Closed 0 : Open
1
P1 “ON”
1 : Closed 0 : Open
2
P2 “ON”
1 : Closed 0 : Open
3-F
(Not used)
