126
Notes:
1. The frequency reference parameters and monitor display data for which this
selection of unit function is valid, are stored in the inverter in units of Hz.
The units are converted as follows.
2. The upper limit for each unit is the figure whose fractions below the significant
digits are cut off.
(Example) Where the upper limit value for the unit Hz is 60.00 Hz and n035 = 39,
120 x 60.00 Hz ÷ 39 = 184.9, accordingly 184 r/min is displayed for the
upper limit value.
For the displays other than upper limit value, the fractions below the significant
digits are rounded.
3. To execute VERIFY for parameter COPY function, frequency reference parameters
(in units of Hz) is applied.
Parameter
n035
Setting
Description
40
to
3999
• Set the display value at 100% of frequency reference (set value of Fmax(n011))
at 1st to 4th digit of n035.
By a number of 4th digit of n035, set the position of decimal point.
By 1st to 4th digit of n035, set a 3-digit figure excluding decimal point.
Number of 4th digit. Position of decimal point 40 to 3999
0
1
2
3 0.
(Example) To display 20.0 at 100% of frequency reference, set n035 to “1200.”
• Setting range
min{(Lower 3-digits of n035) x Frequency reference lower limit (n034) to (Lower 3-digits
of n035) x Frequency reference upper limit (n033), 400Hz (Lower 3-digits of n035) to
Fmax(n011), 999}
Max. upper limit value: (Set value ÷ (Lower 3-digits of n035)) x Fmax(n011)< 400Hz
Setting/Display parameter n035 Frequency reference parameters
Data for monitor d isplay
Display
Setting
system Each unit Units of Hz
