37
• Simple Data Setting
Digital setting (Refer to 5, OPERATING THE INVERTER) and potentiometer setting
are both available for simple accel/decel operation of the VS-606V7.
Frequency reference by analog voltage is set with initial setting (n004 = 1). For the
model with digital operator (with potentiometer) JVOP-140, factory setting is set by
frequency setting potentiometer (n004=0).
Following is an example in which the function LED’s are used to set frequency
reference, acceleration time, deceleration time, and motor direction.
Data setting by frequency setting potentiometer
Status indicator lamp
Operation Steps
Operator
Display
12-LED
Display Status
Indicator LED
1. Turn the potentiometer fully to the left. Then, turn
the power ON.
0.00
RUN
ALARM
2. F/R blinks.
Select FWD/REV run using keys.
Never select REV when reverse run is
prohibited.
FOR
or
REV
RUN
ALARM
3. Press DSPL to blink FREF. Then press RUN. 0.00
RUN
ALARM
4. Operates the motor by turning the potentiometer
to the right. (Frequency reference corresponds to
the potentiometer position is displayed.)
If the potentiometer is switched rapidly,
the motor also accelerates or decelerates
rapidly corresponding to the
potentiometer movement. Pay attention
to load status and switch the
potentiometer movement.
00.0 to
60.00
Minimum
output
frequency is
1.50Hz
RUN
ALARM
FREF
F/R
FREF
NOTE
FREF
: ON : Blinking :OFF : Blinking (Long Blinking)
NOTE
