67 FESTO ELGL-es 0904NH
13 Technical data
ELGL-
30-…-S ELGL-
64-…-S ELGL-
64-…-M ELGL-
120-…-S ELGL-
120-…-M ELGL-
120-…-L
Design properties
Constructional design Electric linear drive in accordance with the hybrid-switched-
reluctance principle (H-SRM)
Mounting position Preferably horizontal, vertical operation permissible on request
(observe additional information, use of supports, …)
End position protection Integrated buffer for slight cushioning energy
(minimal protection)
Measuring principle of
displacement encoder Magnetic incremental
Temperature monitoring PTC resistor integrated
Automatic switch-off in event of over-temperature
Max. motor temperature °C +70
Ambient temperature
Storage temperature
Air humidity
°C 0 ... +40 (if necessary, reduction in nominal power at temperatures
>25°C)
0 ... +60
20 … 80 %, no condensation
Materials Motor housing: Anodised aluminium
Stator: Steel (corrosion-resistant)
Screws: Steel, galvanized
Strength 8.8
Protection class IP 65
Magnetic radiation None
Slide weight kg 2.8 3.8 5.0 4.7 6.8 8.7
Stator weight / Meter kg 4.9 13.3 13.3 27.0 27.0 27.0
Air pressure bar 5 5 5 5 5 6
Air consumption l/min. 15 15 20 15 20 40
