6.4 Connecting the power supply cables

Angled air connection (optional, e.g. QSL-M5-4)

Straight air connection (standard, e.g. QSM-M5-4)

Mounting screws for plug connector (max. tightening torque 1.2 Nm)

The connecting cables can be adapted according to the mounting require-
ments.

Fig. 25
