37

FESTO ELGL-en 0904NH

2

Control elements and connections


Fig. 17

End position limiter with rubber buffer

Stator

Slide

Magnetically coded tape

Sensor (displacement encoder)

Mounting thread for linear axis on the stator (M6x12)

Electrical interface

Air connection

Mounting thread for effective load (M6x9), centring countersink (Dm9H7x2.1)
