AT-8202 ATM Uplink User’s Guide

2-33

ATM/SHOW/PTOP Example

This command displays current configuration for any PTOP entries. A
sample display of

ATM/SHOW/PTOP

is shown below, and

parameters are described in Table 2-15.

.

ATM/SHOW/TRUNK Example

This command displays current configuration for any trunking
entries. A sample display of

ATM/SHOW/TRUNK

is shown below,

and parameters are described in Table 2-16.

.

/ATM/SHOW >

ptop

PTOP

PTOP

PVC/

VCI

ATM

ID

Description

SVC

Value

Address

===

================

======

======

=====================

0

PTOP Instance 0

PVC

500

Table 2-15 ATM/SHOW/PTOP Parameters

Parameter

Description

PTOP ID

The unique PTOP identifier.

PTOP Description

The user-defined description of this PTOP

PVC/SVC

The connection type

VCI Value

For PVC connections only, the virtual channel
identifier.

ATM Address

For SVC connections only, the ATM address of the
ARP server for the logical subnet to which this CIP
is connected

/ATM/SHOW >

trunk

TRUNK

TRUNK

PVC/

VCI

ATM

ID

Description

SVC

Value

Address

===

==================

=======

======

====================

0

PTOP Instance 0

PVC

500

1

TRUNK Instance 1

PVC

501
