Configuring the LAN Emulation Client (LEC)
1-8
Note
If an IP address does not exist for this VLAN, enter an IP address for the
FORMULA 8200 using the
VLAN/CONFIG/VLAN # command. Refer
to the FORMULA 8200 User’s Guide for details.
2. Create the LEC service using the ATM/CONFIG/CREATE/LEC
command.
The LEC Configuration information is shown in the following
screen. Table 1-3 provides a description of the parameters on
the LEC Configuration screen.
/VLAN/SHOW/VLAN
Virtual LAN Information:
VLAN VLAN IP Network Admin Operation Port
ID Description Address Status Status Membership
==== =========== ========== ====== ========= ==========
1 Default VLAN(#1 1.1.1.1 ENABLE ACTIVE 1-16
/ATM/CONFIG/CREATE > LEC 1
LEC Configuration
1. LEC Number: 1
2. LEC Description (Optional):
3. ELAN Name (applicable only in AUTO mode):
4. Use LEC Config Server ATM (Yes(a), No(b)): Yes
5. LEC Config Server ATM Address (Option 5a): 0x47009900000000
00000000000000a03e00000100
6. Control Time-out (in seconds): 10
7. Max. Unknown Frame Count: 1
8. Max. Unknown Frame Time (in seconds): 1
9. VCC Time-out(in seconds): 1200
10. Max. Retry Count: 1
11. Ageing Time (in seconds): 300
12. Expected LE-ARP Resp Time (in seconds): 30
13. Flush Time-out (in seconds): 4
Enter Selection, 0 to save the Modification or ‘q’ to Quit: 0
