ATM/CONFIG/CREATE Commands
2-10
For example, enter 34 to see the following screen:
The screen adds a new option, 7b, to allow the deletion of the
VCI value from the list at a later time.
ATM/CONFIG/CREATE/LEC Example
This command allows the user to create an LEC, where Number> indicates the unique LEC index. If an LEC of that index
already exists, the screen displays the error message,
LEC
Number> already exists .
A sample display of ATM/CONFIG/CREATE/LEC is
shown below, and parameters are described in Table 2-3.
CIP Configuration
1. CIP Index: 7
2. IP Address: 137.168.132.7
3. IP Subnet Mask: 255.255.255.0
4. Description (Optional): CIP Test 7
5. Admin Status (ENABLE(a), DISABLE(b)): ENABLED
6. Connection Type (PVC(a), SVC(b)): PVC
7. VCI List: 34
(Add VCI to List (a)
Delete VCI From list (b))
8. Arp Server ATM Address (Reqd if SVC):
9. Mtu Size: 9180
10. IP RIP mode (Active (a), Deaf (b), Silent (c), Inactive (d)): Silent
Enter Selection, 0 to save the Modification or 'q' to Quit: 0
